5M-AOV 4G Dome Module

5M-AOV 4G Dome Module

Consult & Quote Download Specs

AOV Intelligent Dual-Light Dome Module

HX6301S-5M-AOV-CAT1L-MF-B

1、Appearance









2、Introduction

The 5MP AOV intelligent dual-light module, featuring an embedded LINUX system and a 5MP low-light sensor, delivers a max resolution of 2880x1620. It supports H.265/G.711 encoding and customizable bitrates. In AOV mode, it records at 1fps or 0.5fps (0.16W power), switching to 15fps under full activation.Storage options include TF cards,FTP server and cloud storage, with two-way audio and optional 4G (EU/US/JP variants).

Equipped with human detection, and detection up to 30 meters. Intelligent dual-light, it automatically activates infrared monitoring in AOV mode at night, switching to warm light full-color imaging with full frame rate upon target detection.

3、Main Characteristics

5MP( 2304x1296) High sensitivity, high S/N CMOS image sensor.

H265 compression algorithm, support dual stream.

Enable mobile phone monitoring with CamHipro and show battery stats on APP.

Support multiple network protocols: TCP/IP,HTTP,TCP,FTP,UDP,NTP , ARP,DHCP,DNS ,etc.

Support Human Detection Alarm(max 30m Range) and human tracking.

Support alarm recording to TF card(128G) /FTP server or cloud storage (requires purchasing).

Supports AOV mode recording with 1fps or 0.5fps.

Supports 5-user simultaneous browsing at most.

Support mobile phone downloading and playback TF card recordings.

Supports customizable detection zones and human-form sensitivity settings.

Supports 4G EU/US/JP.


4、Parameter

HX6301S-5M-AOV-CAT1L-MF-B


Operating System

Embedded LINUX

Image Sensor

1/3” CMOS sensor

IRCUT

Support

Video/Audio Codec

H.265/G.711

Video Bitrate

384-6144Kbps(Customizable), Default 1024Kbps

Resolution

2304x1296

Video Frame Rate

15fps(50HZ), 15fps(60HZ) / AOV Mode:1fps or 0.5fps

Character Overlay

Supports OSD overlay of name, time, and date

Image Settings

Brightness, Contrast, Saturation, Exposure, Flip (Vertical/Horizontal)

Motion Detection

Detection Area: 1 | Sensitivity: 1-100

AI Alarm

Humanoid Detection: Range 30m

Recording Mode

AOV Mode /Alarm Mode

Recording Storage

TF Card(128G) / Cloud Storage(requires purchase) /FTP Server

Alarm Recording Duration

15s or 30s, default 15s

Alarm Linkage

Alarm Recording to TF card/cloud Storage /FTP Server, and sound output.

Two Way Audio

Support

Network Protocol

TCP/IP, HTTP, TCP, FTP,UDP, ARP, DHCP, DNS, NTP

View & Browse

CamHipro APP

Audio I/O

MIC *1, Speaker *1

Network Options

4G(EU/US/JP)

Module Size

(LWH）70x50x11mm

Temperature/Humidity

0℃ ~ +50℃ / 10%～95%RH

Power Supply

DC5V 2A

Power Consumption

Operating Mode: 1.2W; AOV mode: 0.16W(IR off)/0.28W(IR on)
